From Here to There, from Where to Here
Patterns for Web API Query Parameters
There are many different patterns for using query parameters in web APIs. Today’s article in my API Design Patterns series in API Design Matters is about query parameters in Web APIs. Let’s explore some of these patterns…
It is what it is
In HTTP APIS, query parameters occur after the path and before optional anchor tags in a URL. The query parameters begin with the ? special character, which is followed by a &-delimited list of name=value pairs
It’s quite natural to interpret this = character to mean equality, i.e ?x=6 means “where x equals 6”. However, I prefer to interpret this = character as “is” , such as “where x is 6”
Thus, one can read or “interpret” a URL such as the following (ignore line breaks)
http://api.chainlinks.example.com/universes
?author=au345bd84
&genre=fantasy
as
universes where
the author is (the author with idau345bd84)
and genre is “fantasy”
I find this style slightly more literate as well as more flexible than a rigid “equals” interpretation.
Filtering List Operations
For consistency across APIs, I use query parameters to, as the name implies, parameterize the query. What does this mean? Most commonly, I use query parameters to serve as filters on List operations, as a means of subsetting the response list to a narrower set that satisfies the conditions defined in one or more query parameters.
In these cases, the interpretation of the query parameters is done with an implicit context of an element of the referenced collection.
In our Chain Links API, one such collection is the chainLinks resource. A chain link has several properties:
author - the author who created/write the chain link
a set of characters who are mentioned in or are part of the chain link
the
universein which the chain link occursthe date when the author create/wrote the chain link (
authoredOn)
Thus, we can use these property names as query parameter names to subset the list response to those chain link instances whose property values match the query parameters.
The next design decision is what query parameter values to use after the = sign. For author and universe query parameters, we want to allow the client to pass the author’s resource ID (author names are not unique) or perhaps the author’s URI. Similarly, it is most convenient for the client to pass the resource ID for for a universe resource
As I wrote in From Domain Model to OpenAPI, one can parameterize the request to return a list of chain links:
GET /chainLinks?character={someCharacterId}
GET /chainLinks?universe={someUniverseId}
GET /chainLinks?author={someAuthorId}
GET /chainLinks?authoredOn=[2023-01-01,2023-03-31]I hope the first three are intuitive. A common pattern is to filter resources on a range of values, such as a date range. In banking APIs (such as filtering a list of transactions), it’s common to filter based on a range of values. I like using range notation as shows with the date range above; this works for numeric values as well, such as GET /banking/accounts/{accountId}/transactions?amount=(0,100.00] to match transactions whose amount is greater than 0 and less than or equal to 100.00.
I’ve seen lots of other query designs for ranges, such as
?amount=gt:0&amount=le:100.00
?filter=and(gt(amount,0),le(amount:100.0)
?where=amount > 0 and amount <= 100
?$filter=amount gt 0 and amount le 100.00The last one is based on OData. It and the ?where style before it are more common in APIs which directly expose the underlying data schema. However, this is more of an anti-pattern in modern web APIs, which are more robust when they support (or even enforce) an abstraction layer between the API consumer and the back-end system behind the API. Mike Amundsen put this eloquently when he wrote
"Remember, when designing your Web API, your data model is not your object model is not your resource model is not your message model." — Mike Amundsen
(Mike shared this in 2016 on a social media microblogging site that I choose to not quote here. However, you can read more about it at What is Amundsen's Maxim?)
In other words, if you expose the current data schema of your (internal) database, you lock your API into that implementation, or you risk breaking clients if you wish to refactor the database. (Mike followed up the original message with a clarification: “we need to be able to design/implement each aspect (data, object, resource, representation) independently without breaking the others.”) Thus, I advise against adopting any query parameter patterns that expose the back-end implementation details of the API web service. I think this emphasizes the main purpose of following good API design and API design patterns: Expect change, and use API design to hide the API consumer from changes which should not impact them.
Getting back to our other patterns, I hope you can see why I think that interpreting = in a URL’s query parameters as “is” works better than “equals”, such as:
?amount=gt:0&amount=le:100.00amount is gt 0 and amount is le 100.00
Some of these obviously require URL encoding, namely:
?amount=(0%2C100.00%5D // ?amount=amount=(0,100.00]
?amount=gt%3A0&le%3A100.00 // ?amount=gt:0&amount=le:100.00
?amount=and(gt(amount%2C0)%2Cle(amount%3A100.0)
?where=amount%20%3E%200%20and%20amount%20%3C%3D%20100
?$filter=amount%20gt%200%20and%20amount%20le%20100.00Unfortunately, none of these are very legible once they have been URL encoded.
I like the range notation (also known as interval notation) because it has existed in mathematics since before I first studied math (decades ago). It is concise and very flexible. The ( and ) characters denote open ended intervals (the interval does not include the adjacent endpoint) and the [ and ] characters denote closed-ended intervals (the interval includes the adjacent endpoint):
?amount=(20.0,100.0] : amount > 20.0 && amount <= 100.0
?amount=[20.0,100.0] : amount >= 20.0 && amount <= 100.0
?amount=(20.0,100.0) : amount > 20.0 && amount < 100.0
?amount=[20.0,100.0) : amount >= 20.0 && amount < 100.0
?amount=(20.00,) : amount > 20.0
?amount=[20.00,) : amount >= 20.00
?amount=(,100.0] : amount <= 100.00
?amount=(,100.0) : amount < 100.00This or That, Here or There
One additional query parameter pattern I use comes in handy when you wish to express a condition where a resource’s property is one of a small list of values (usually string enumerations). I.e. to capture the condition of testing if the state property of a chain link is one of three values, draft, published, withdrawn, the desired natural language query is something like
List chain links where the chain link’s state is either draft or published or withdrawn
As a query parameter, the OpenAPI Specification allows defining a query using an pipe-delimited array. This is convenient because the pipe character, |, is used as a binary or operator in several programming languages. Thus, this filter maps to query parameter notation
?state=draft|published|withdrawn
In OAS 3.x notation, one can define a parameter:
parameters:
- name: state
in: query
explode: false
style: pipeDelimited
schema:
type: array
minItems: 1
maxItems: 3
uniqueItems: true
items:
$ref: '#/components/schemas/ChainLinkState'The ChainLinkState schema is defined with a JSON schema such as
components:
schemas:
ChainLinkState:
title: Chain Link State
description: The state that a chain link resource may be in.
type: string
enum:
- draft
- published
- withdrawnThe schema for the query parameter further constrains the parameter, allowing an API service to validate the value and reject invalid queries such as
?state= # minItems constraint violated
?state=garbage # items enum constraint violated
?state=draft|draft|draft|draft # maxItems / uniqueItems: true
# constraint violatedI prefer using named schemas for such cases compared to putting the enum schema in line in the parameter definition, as this helps Software Development Kit (SDK) code generation tools generate cleaner code. Absent named schemas, code generation tools often construct new names for data types based on the context or location, and I find the result somewhat unsatisfactory.
Parameterizing Operations
Query parameters can parameterize other operations, not just List operations. I try to avoid mixing request body data with parameterization. For example, when creating (POST) or updating a resource (PATCH or PUT), I put all the data necessary to create or update the resource in the request body. Query parameters may alter how the operation is performed, but the request body conveys what data to use.
For example, see how the ?dryRun= query parameter alters the behavior of a POST or other operation in Validating API Requests. There, the value of the ?dryRun= query parameter is not part of the request body payload — it does not get stored in the resource. Instead, this parameterizes the operation, requesting that the server stop short of creating or updating the resource, so that the client can let the API service perform full validation of the request.
Your Options
There are many conventions and patterns for Web API query parameters. It’s less important which style you choose, but as with any pattern, what is more important is that you use it consistently across your APIs.
