API Design Antipattern: Leaky Abstractions

Pro tip: Do not let internal implementation constraints leak into your API

In this edition of API Design Matters, I will discuss an API design practice that I recommend avoiding — leaking internal implementation details into the API design. This does not fit the original definition of an antipattern*¹ but I’m going to use that term anyway and call Leaky Abstractions an API Design Antipattern.

Exposing internal implementation details in an API design has negative consequences:

1. If the API design is too coupled to the underlying system, changes to that internal system likely will require changes to the API, which in turn can disrupt the API’s clients and consumers.

2. Such detail often reflects cultural, historical, technical and other influences that pertain to the engineering team, requirements, system and other constraints for a different scenario or problem set than the API. As such, the internal implementation decisions may not address the needs of the API. For example, databases are often design to optimize for certain access patterns of the system or application they were originally built to support. Such patterns may be very different for an API that is designed to use that data at a later time.

3. Internal system design often uses jargon or concepts that are unrelated to the conceptual model that your API consumers have of your system. This impedes adoption of your API.

Thus, one should avoid letting the internal system design leak into the API in order to create and maintain an API abstraction that fits the API consumer’s needs. Don’t sacrifice API usability just to facilitate expediency in the API implementation.

(Corollary: avoid generating an API directly from a database schema.)

Here is a more concrete example. I recently saw the following construct in a third party API (I renamed the schema to keep the vendor anonymous, but I did not change the enum names.)

...
components:
  schemas:
    CommunicationMethod:
      title: Communication Method
      enum:
        - FAXI
        - EDIC
        - URID
        - EMAL
        - POST
        - SMSM
      type: string

Unfortunately, the schema that defines these enum values does not define what these values mean... this is understandable, since OpenAPI and JSON Schema do not provide a specific notation for describing what each enumeration in an enum list means. Still, a better developer experience calls for a description that tells the reader what each of these values means.

In this case, the descriptions of these values appear elsewhere in the OpenAPI source file, in the description of a property that is constrained by the schema. If this schema is needed elsewhere, it is likely the API author would either not describe the values at all or, more likely, follow the existing code pattern and duplicate this verbose description. The result would be fragile — if the API needed a new value in the list, this would require updating multiple descriptions in the API definition. This violates the Don’t Repeat Yourself (DRY) Principle, which I’ve discussed before:

However, this WET (“Write Everything Twice”) design is not the real API design antipattern I want to discuss. Instead, it is the names of these enumerated strings that strike me as a leaky abstraction. Here is the definition of the property which uses this schema:

      properties:
        method:
          $ref: '#/components/schemas/CommunicationMethod'
          description: >-
            The method used to deliver the the status to the originator.
            - `EMAL` - Email
            - `URID` - URI (HTTP URL or similar)
            - `POST` - Postal services
            - `SMSM` - Short Message Service (SMS)
            - `FAXI` - FAX
            - `EDIC` - Electronic Data Interchange

Unfortunately, this API appears to leak some internal implementation constraints --perhaps this format is required by a separate pre-existing back end service, or some internal communication protocol, or perhaps even a database table where only 4 characters are allowed and EMAIL would not fit. However, there is no need to let such internal constraints affect the API design by constraining these enum strings to four characters with reduced readability and diminished self description.

The purpose of an API is to provide an abstraction of the underlying service. That abstraction should be expressed in terms the API consumer can use and understand, not just what is convenient for the implementor. The goals of the API designer—and implementor—should be to do the hard work to make the API easier to learn and use.

The above example highlights several issues which decrease the API usability. For example:

• I believe EMAIL would be much better than EMAL. Why decrease readability and increase cognitive load by removing just one letter? The abbreviated spelling reduces one’s ability to discuss (talk about) the API - i.e. one cannot simply mention EMAIL in a conversation and have it be easily understood - one might even have to spell it out E-M-A-L to avoid miscommunication.

• Why add an I to FAX, or add C to "EDI" (Electronic Data Interchange) or add an M to "SMS" Short Message Service (SMS) or add a D to URI — just to make them all 4 character strings? The terms FAX, EDI, SMS and URI are well-known, recognizable names; adding extra characters to them only obfuscates them, especially when the given definitions do not explain why those extra characters are there:

• SMSM - Short Message Service (SMS)

• FAXI - FAX

• EDIC - Electronic Data Interchange

• URID - URI (HTTP URL or similar)

I don’t know the origin of these names, but I suspect they came directly from implementation code. However, this semantic gap between the names and what they represent only increases API friction. There is no justification given here for why these enum values are named as they are (perhaps because there is no good rationale). The API design only makes consumers stop and ask “Why?” When this happens, the API design detracts from the API’s purpose and becomes a pointless distraction.

Your API design should anticipate and answer the domain questions your consumers may have; it should not raise additional questions in their minds; nor should reading or using the API be frustrating.

A useful tip is to always look at your API Design from the perspective of someone who has never seen your system before and does not have the same institutional knowledge that your API team has.

1. Martin Fowler defines antipattern as “something that seems like a good idea when you begin, but leads you into trouble. Since then the term has often been used just to indicate any bad idea, but I think the original focus is more useful.”
I’m using the latter interpretation of the term.
