Understanding the Language of API Security
How OpenAPI expresses API security.... and how it does not
In today’s issue, we begin a deeper dive into keeping APIs secure. I hope you do not mind me assuming that you know why API security is important. The how is harder, and there are many facets of API security. We begin by exploring what can and cannot be expressed with OpenAPI 3.1.
Welcome to the next article in the Language of API Design. Rather than jumping into the middle of this series, I encourage new subscribers/visitors start by reading Your Guide to The Language of API Design and scanning previous posts in the series.
The OpenAPI Specification (OAS) is a domain-specific language (DSL) for defining HTTP APIs. As a language, it has a fixed syntax, and is thus constrained by the expressiveness of that DSL. Let’s explore that language of APIs a bit more as it pertains to the security aspects of APIs.
OAS provides two primary structures for defining an API’s security:
Security Schemes define the kind of authorization required to use the API. Each security scheme has a required security
typeand additional properties which configure and constrain that security scheme.Security Requirements specify which authorization a caller must supply when invoking an API operation, along with the authorization scopes that the caller’s authorization must include. (We’ll explain scopes below).
In addition to this explicit description of API security, there is also implicit security scattered throughout OAS’s expression of an API. Quite a bit of security concerns are embedded in JSON schema, which we’ve touched on in previous posts and which we will explore in more detail in the next post.
Sample Security Schemes and Requirements
In order to secure an operation in our sample Chain Links API, we must complete a domain analysis of the API and understand the actors and what they do. For example, only the authenticated Author should be allowed to edit or delete their author resource or to view their account details. We must also evaluate our options for authentication and authorization for the Chain Links application and API. For example, we can reject Basic authentication, as it is too insecure. For now, assume we have chosen to use OpenID Connect for Chain Link API’s authentication/authorization.1 This is (in my opinion) the most robust API authentication model that is directly expressible in OpenAPI.
We can express this in the OpenAPI source by defining a security scheme with type: openIdConnect in the securitySchemes of the API components:
components:
securitySchemes:
oidcAuthCodeFlow:
type: openIdConnect
...securitySchemes is an object; the keys are the names of the schemes, and the values are their definitions, as per Security Scheme Object.
The name allows the security scheme to be referenced later. We choose the name oidcAuthCodeFlow here.2 To make our security scheme complete, we add a description and the required openIdConnectUrl:
components:
securitySchemes:
oidcAuthCodeFlow:
type: openIdConnect
description: >-
OpenID Connect authorization using OAuth2
Authorization Code Flow.
openIdConnectUrl: >-
https://auth.chainlinks.example.com/oidc/.well-known/openid-configurationThe openIdConnectUrl is the OpenID Connect discovery URI which a client uses to perform the OAuth2 Authorization Code Flow that is part of OpenID Connect. The client performs a GET on that URL to fetch a JSON representation of the authorization server’s OIDC metadata. Note: This process should be done with a client library that implements the authorization flow.
Here is an example of defining OAuth2 authorization:
components:
securitySchemes:
oauth2AuthCodeFlow:
type: oauth2
description: >-
Authorization via OAuth2 Authorization Code Flow.
flows:
authorizationCode:
authorizationUrl: >-
https://auth.chainlinks.example.com/authorize
tokenUrl: >-
https://auth.chainlinks.example.com/token
refreshUrl: >-
https://auth.chainlinks.example.com/refresh
scopes:
author/read: Read Author resources
author/update: Update Author resourcesYou’ll notice that this is much more complex that the OpenID Connect scheme, because OpenID Connect buries that complexity in the discovery protocol: the authorization and token URLs are discovered while negotiating the authorization. For OAuth2, the configuration has to be spelled out (i.e. “discovered” via the OpenAPI document). There is a higher degree of Convention over Customization with the openIdConnect scheme. (Hey, Convention over Customization: Big fan.)
Once your security schemes are defined, you can annotate your APIs operations with a security requirement. For example, to specify that the patchAuthor operation requires authorization via our oidcAuthCodeFlow security scheme, we express this in OpenAPI as:
paths:
/authors/{authorId}:
patch:
summary: Update an author
description: ...
operationId: patchAuthor
security:
- oidcAuthCodeFlow: [ author:update ]Understanding the Language of API Security
The language of this security object is not immediately evident, so let’s explain the meaning of a security requirement. The security keyword introduces the operation’s security requirement, which is expressed as an array of objects. This structure is a bit clearer if we show the JSON equivalent:
"security": [
{
"oidcAuthCodeFlow": [
"author:update"
]
}
]In the example, the array has only one element, and that object has only one key/value pair. The key is the name of a security scheme ( oidcAuthCodeFlow in this case, matching the scheme we defined above ) and the value is always an array. If the security scheme’s type is oauth2 or openIdConnect, the array is a list of scopes. For all other security scheme types, the array must be empty.
That array of scopes lists the OAuth scopes that the client must be granted during the authorization flow in order to use the API operation. (Explaining all of the OAuth flows, or event the basics of the Authorization Code Flow, is beyond the scope of this article.3) Each scope represents a specific access to an API operation or resource. In this example, the scope author:update grants access to updating an author within the Chain Links API. If the current authorization does not include all of the scopes in the security requirement, then the API should reject the request with a 403 Forbidden response code.
Tip: Scope names often take the form of “
noun:verb” or “noun/verb”, where thenounnames a resource and theverbnames an action performed on, against, or with that resource.
You may have noticed an interesting difference between OAuth2 and OpenID Connect security schemes: You must define the scopes with OAuth2, but you cannot define the scopes with a OpenID Connect scheme. Like the authorization and token URLs, the scopes are defined in the OIDC discovery JSON data. This unfortunately means the descriptions of the OIDC scopes are not available in the OpenAPI document, even though the security requirements must still list the operation’s required scopes.
Defining an Operation’s Security Requirement
An operation’s Security Requirements specify which authorization a caller must supply when invoking an API operation and the authorization scopes that the caller’s authorization must include.
OpenAPI provides a very flexible means of composing the security requirements as an array of one or more objects, in the security value of an OpenAPI operation object.4
...
operationId: identifiero
security:
- security-requirements-object1
- security-requirements-object2
- ...
- security-requirements-objectnThe caller must provide authorization that matches at least one of the n security requirement objects.5
Each security-requirements-objecti is an object consisting of key/value pairs, where the key is the name of a security scheme and the value is an array of scopes necessary to invoke the corresponding operation:
security-requirements-objecti = {
scheme-name1 : [ scope1a, scope1b, ..., scope1x ],
scheme-name2 : [ scope2a, scope2b, ..., scope2x ],
...
scheme-namem : [ scopema, scopemb, ..., scopemx ],In order to match a security requirement object, the API call must satisfy all of the m elements of the security requirement object. The security requirements notation—a mini-language, if you will—is a concise representation of an implicit OR of ANDs.
Consider this contrived example involving 7 different security schemes s1 through s7 using scopes a:read b:read and c:read.
security:
- s1: [ a:read, b:read ]
s2: [ b:read, c:read ]
- s3: [ a:read, b:read ]
s4: [ b:read, c:read ]
- s5: [ a:read, b:read ]
s6: [ a:read, b:read ]
s7: [ b:read, c:read ]This notation expresses the equivalent of the following logical combination. (I’ve omitted the scopes to make the logical structure clearer.)
( s1 AND s2 )
OR ( s3 AND s4 )
OR ( s5 AND s6 AND s7 )The security requirements notation is a
concise representation of an implicit OR of ANDs.
This notation is fairly expressive, yet quite concise. Most uses are not nearly this complex. Luckily, many times, both n and m is are 1, such as:
security:
- oidcAuthCodeFlow: [ author:update ]Caution: More complex security requirements result in more complex SDKs!
Consistent… Except When It Is Inconsistent
With OAS, the references to security schemes in a security requirements object are only by name, and not via a $ref (reference object). This means that the named security scheme must be defined in the same source file as the operations that use it.
This differs from how one references OAS components elsewhere. A $ref allows an element in one OpenAPI document to reference a component defined in the document or in another OAS document. However, one cannot do that within security requirements—one can only name a security scheme defined in the same document.
Tip: this is not a serious problem, because you can still code the security schemes in a reusable component source file accessed relative to the current file (such as
common.yaml) and then put the$refto those schemes in the same OAS document with the operations—a sort of daisy-chain effect:components:
securitySchemes:
oidcAuthCodeFlow:
$ref: >-
common.yaml#/components/securitySchemes/oidcAuthCodeFlow
Normally, I’m a big advocate of consistency. One might say that I consistently advocate for consistency. It’s important—for good Developer Experience—for an API to be consistent:
Consistent within itself (i.e. across schemas and operations)
Consistent with other APIs
Consistent with standards.
But I guess every rule has its exceptions.6 Had security requirements used $ref notation instead of just names of security schemes, its expression would be much more cumbersome and verbose, with little benefit.
So What’s Missing?
We’ve seen that APIs defined with OpenAPI can use a variety of API security schemes. While all of these represent authorization to use API operations, none of them express data-level entitlements (also known as row-level security), such as which bank accounts the user has access to out of all the accounts held at a bank.
The oauth2 security scheme lists the names and descriptions of all the scopes, which allows validation that the security objects for the API operations use only scopes that are defined. This also provides a description of each scope in any API documentation you generate from the OpenAPI document. In order to full understand the scopes when using openIdConnect, the tooling must fetch the OIDC discovery document and check its scopes, although that document is not guaranteed to be available to such tools.
Also, while the servers object in an OpenAPI document can use variables to parameterize the URL by which the API is invoked, one cannot use server variables to parameterize the authorizationUrl, tokenUrl, or openIdConnectUrl. Project Moonwalk, the OpenAPI Initiative’s work on version 4 of the OpenAPI Specification, may address this shortcoming. Using a relative URI instead of an absolute URL (so that the OIDC configuration is relative to the runtime API base path) can also help.
In the next issue of API Design Matters, we’ll look at less explicit means of securing APIs with the OpenAPI Specification: Defining 401, 403, and 404 response codes7, and specifying strict JSON Schema constraints. Stay tuned!
OpenAPI defines other security scheme types:
httpauthorization, using thebasicformat, uses anAuthorizationheader with an encoded username:password string which is easily decoded, and thus inherently very insecure. (It is quite easy for a malicious actor to steal your user ID and password.) I strongly recommend against using authorization based onbasicauthentication.The
httptype may also be used with thebearerformat to pass a Java Web Token for authorization.apiKeyis a way to pass one or more an authorization strings on each operation, in different request headers. This is also not very secure (and in fact is not really API security—API keys are really mechanisms to identify the client making the API call. However, an apiKey security scheme can be used to implement other non-standard security protocols.mutualTLSis used for client certificate based security. The client passes an encoded certificate with the request and the lower level Transport Layer Security (TLS) tier validates the certificate at the edge. The certificate identifies the user and represents their authorization to use the service. Oddly, the OpenAPI specification does not define what the mutualTLS security scheme is; it is simply implicitly client certificates via TLS.
This name informs readers that authentication is done via OIDC and uses Authorization Code Flow—a secure way to obtain authorization in otherwise insecure applications like web and mobile apps.
Did I just say that scopes are out of scope?
You can define a general security object at the root of the OpenAPI. The defines a default security requirement that applies to all operations that do not explicitly define their own security requirements. However, with OAuth2 or OpenIDConnect security, different operations often require different fine-grained sets of scopes, so it is less common for a document-wide default security requirement to work well… unless one defines a very broadly applicable scope that covers multiple resources and multiple actions, or one partitions operations into separate OpenAPI document based on the scopes. While possible, this does not seem to be a useful way to organize APIs.
Luckily, most of the time, n is 1!
Does the rule “every rule has its exceptions” have an exception? Kurt Gödel or Douglas Hofstadter may know…
Much easier and much more concise than defining 401,403,404 response codes.
