Welcome to the next article in the Language of API Design. Rather than jumping into the middle of this series, I encourage new subscribers/visitors start by reading Your Guide to The Language of API Design and scanning previous posts in the series.
In the last article of The Language of API Design series, you saw how to express a few HTTP API operations to list resources in the Chain Links domain model, focusing on the design for calling the getChainLinks operation. (If you are just jumping into API Design Matters, I recommend going back and skimming the previous articles in the The Language of API Design series to get caught up.)
Now you know how to express a GET operation to list chain links and filter the list by some useful attributes of the items in it. But if your relationship with your API is one-sided—all talk and no listening—it won’t be very satisfying. You need to get something out of the relationship!
In this article, we’ll explore how you get something out of the API: how to design API responses to fit your consumer’s needs. We’ll continue with the getChainLinks operation. Our tasks for today:
Modeling the response representation that contains a page of chain link items
Defining the
getChainLinksoperation responses
These techniques can be applied to the other resources in the API in a straightforward manner…. there’s that “API design pattern” concept again!
Modeling the response that contains a page of chain link items
First, let’s work out the design for the API response. It should be a page of chain link items—this implies an array type.
For our first approximation, we want the JSON response to look like the following:
[
{
"id": "cl-489fjkd-49d9d",
"type": "text",
"authorId": "au-4639fjk3-fjkf",
"createdAt": "2023-03-08T20:22:50.000Z"
},
{
"id": "cl-f89jf-3jkdkh",
"type": "text",
"authorId": "au-4639fjk3-fjkf",
"createdAt": "2023-03-08T21:44:05.000Z"
},
{
"id": "cl-d9h4d83-dh49dhe",
"type": "image",
"authorId": "au-4639fjk3-fjkf",
"createdAt": "2023-03-08T22:58:37.000Z"
},
{
"id": "cl-478d9d-4hjdhj93",
"type": "text",
"authorId": "au-4639fjk3-fjkf",
"createdAt": "2023-03-08T23:52:19.000Z"
}
]Each item is a brief summary of a chain link. In API speak, each item is just one representation of a chain link. It includes some but not all of the properties of a chain link, as listed in the domain model:
The
idto identify this chain link. Thisisneeded so the client can fetch the full representation of a chain link withGET/chainLinks/{chainId}The type of chain link (text, image, etc.)
The ID of the author
Timestamp when the chain link was created/authored.
I follow a style convention for date and time property names in APIs. I use names such as “
createdAt”, with an “At“ suffix, to denote date-time or instant values, and names such as “joinedOn”with an “On“ suffix for date properties without a time component.
We need only include the properties necessary for the consumer to view or list the chain links, not all the fields in the full representation of a chain link. (Thought experiment: What obvious property is missing from this list, which would make a list of chain links better?)
This use of a concise summary representation of a chain link highlights an important point of API design: there can be multiple representations of the same resource. Each representation serves a specific purpose. A different representation of a chain link may include other details not present in the list item representation, including references to chains which include that chain link, or universes or characters mentioned in that chain link, or many other properties. In our case, these are all JSON representations. There can also be non-JSON representations, such as the rendered version of the chain link when a user reads the assembled chain, or a thumbnail image of a large image chain link.
In an API, there can be multiple representations of the same resource
The above array representation looks fairly straight forward. However, I avoid returning arrays as top-level API responses because arrays do not allow for API evolution. We all know that APIs change over time, and using an object schema allows an API to evolve more naturally: you can add new properties to an object in future releases of the API when new requirements emerge. You cannot add new properties to an array. You will see the greater flexibility of using an object when we add support for paginated responses, and later in API Design Matters when we take a deep dive into HATEOS.1
So instead of an array, we will return an object that contains the array. When I design such collection responses, I uniformly name the array field “items” rather than name the array of chain links “chainLinks“ or name the array of authors “authors“ in the getAuthors response, etc. This is a style preference, which I do for consistency and predictability across APIs. For example, this naming allows API clients to treat all collections uniformly via response.items accessors. The client code to check if the collection is empty can use response.items.length == 0 instead of different code for each collection. Pro Tip: Use whatever convention you like, but make it a pattern and apply it consistently across your APIs. API Design Patterns Everywhere…
Defining the getChainLinks operation responses
Now that we know what we want our JSON response to look like, OpenAPI requires us to define data type and shape of data with a JSON Schema and connect it to the getChainLinks operation. This includes the request and response bodies, and as we saw in the previous article, the type and shape of query and path parameters, and even request and response headers.
First, let’s walk through the JSON Schema modeling. JSON Schema is a complex topic—a rich field for future API Design Matters articles, certainly—so we’ll come back to it frequently.
We want a schema with an items property, and each item is an object that contains the id, type, authorId, and createdAt properties. Here is a complete JSON Schema to describe the response from getChainLinks:
title: Chain Links
description: A page of chain link items from a
collection of chain links.
type: object
properties:
items:
title: Chain Link Items
description: A list of chain links in this page.
type: array
maxItems: 10000
items:
title: Chain Link Item
description: A concise representation of a chain link item
in a list of chain links.
type: object
properties:
id:
description: This chain links unique resource identifier.
type: string
minLength: 4
maxLength: 48
pattern: ^[-_a-zA-Z0-9:+$]{4,48}$
type:
description: Describes what type of chain link this is.
type: string
authorId:
description: The ID of the author who created this chain link.
type: string
minLength: 4
maxLength: 48
pattern: ^[-_a-zA-Z0-9:+$]{4,48}$
createdAt:
description: The RFC 3339 `date-time`
when this chain link was created.
type: string
format: date-time
example:
items:
- id: cl-489fjkd-49d9d
type: text
authorId: au-4639fjk3-fjkf
createdAt: 2023-03-08T20:22:50Z
- id: cl-f89jf-3jkdkh
type: text
authorId: au-4639fjk3-fjkf
createdAt: 2023-03-08T21:44:05Z
- id: cl-d9h4d83-dh49dhe
type: image
authorId: au-4639fjk3-fjkf
createdAt: 2023-03-08T22:58:37Z
- id: cl-478d9d-4hjdhj93
type: text
authorId: au-4639fjk3-fjkf
createdAt: 2023-03-08T23:52:19ZI won’t explain everything here—it should be somewhat self-explanatory, thanks to the great descriptive nature of JSON Schema. Just note that the first use of items is to define the items property of the response object; the second use is to define the schema of items in the array.
A more detailed treatment of the many subtleties of JSON Schema merits a few dedicated articles in API Design Matters, but there are a few things to point out quickly:
Each property definition in a
propertiesobject is itself a JSON schema.I always explicitly define the
typeof every schema. Although some JSON schema constraints may lead you to assume a type (apropertiesobject impliestype: object; theminItems,maxItems, oritemsconstraints implytype: array), this does not in fact define or specify a strict type. These constructs merely specify validation criteria. That is, if a JSON value is an array, theitemsconstraint in the JSON schema applies to the array items. However, if non-array JSON value (such as a boolean true or a string “API Design Matters”) is still valid against a JSON schema that defines items but does not explicitly specifytype: array. Similarly, if the schema has properties but does not declare type: object, those same values will also be valid against that schema.JSON Schema is really a language for validating whether JSON data conforms to a schema. It’s use as a modeling language to define data models is secondary, so some interpretation of JSON Schema constructs is required. More on this later.
Next, let’s define the 200 OK response for the getChainLinks operation. Each operation’s responses are defined, as you might expect, in a responses object within the operation object. The responses object is a map whose keys are the HTTP response codes (or patterns that cover a range of response codes such as 5XX), and a response object description of the API response that correspond to that response code. This is further broken down into the definition of any response headers that may accompany the result and a content object whose keys are media types, such as application/json or text/plain or image/png etc. and the definition of the response body for that media type.
operation object:
responses object:
'200':
content:
media-type:
schema:
# a JSON schema defining the representation
# corresponding to the media-type
headers:
Header-Name:
description:
schema:
# a JSON schema defining the response header(We don’t have any response headers yet, so we’ll defer that discussion until later.)
Tying this all together, we merge the layout of the responses object and the 200 response with the schema definition for the JSON representation of the list of chain link objects, and we have the following:
paths:
/chainLinks:
get:
operationId: listChainLinks
summary: List the chain links
description: Return a paginated list of the
chain links in the system.
tags: [ 'Chain Links' ]
responses:
'200':
description: OK. The operation succeeded.
content:
application/json:
schema:
title: Chain Links
description: A page of chain link items from a
collection of chain links.
type: object
properties:
items:
title: Chain Link Items
description: A list of chain links in this page
type: array
maxItems: 10000
items:
title: Chain Link Item
description: A concise representation of
a chain link item in a list of chain links.
type: object
properties:
id:
description: This chain link's
unique resource identifier.
type: string
minLength: 4
maxLength: 48
pattern: ^[-_a-zA-Z0-9:+$]{4,48}$
type:
description:
Describes what type of chain link this is.
type: string
authorId:
description: The ID of the author who
created this chain link.
type: string
minLength: 4
maxLength: 48
pattern: ^[-_a-zA-Z0-9:+$]{4,48}$
createdAt:
description: The [https://www.rfc-editor.org/rfc/rfc3339#section-5](date-time)
when this chain link was created.
type: string
format: date-time(Download this excerpt as an OpenAPI file)
From this example, it is quite easy to apply this to the other list operations in the API… but there is a better way, so hold off going full bore just yet. In an upcoming article in The Language of API Design series, you will see how to Keep your OpenAPI DRY through the use of reusable OpenAPI schema and other OpenAPI components.
Next up:
Modeling the error responses that the API returns when a client request has an error such as invalid query parameters.
Supporting pagination
HATEOAS - Hypermedia As The Engine Of Application State, a principle of REST APIs and a really difficult initialism. My colleague Michael Johnson taught me to pronounce it “Hypermedia”.. It is a broad and important topic (the concept, not the pronunciation) which I don’t have room to discuss here.
